200 series, Vario induction cooktop, 24"
200 series, Vario induction cooktop, 24"
Call for our best price
Dimensions
Width: 22 13/16
Height: 4 15/16
Depth: 20 3/16
Color
Features
- Can be combined with cooktops of the Vario 200 series to a harmonic unity
- Control panel for comfortable and secure operation
- 1 induction cooking zone ø 11" (2600 W, with booster 3600 W).
- 1 induction cooking zone ø 7" (1800 W, with booster 3100 W).
- 1 induction cooking zone ø 6" (1400 W, with booster 2200 W).
Product Description
Can be combined with cooktops of the Vario 200 series to a harmonic unity Control panel for comfortable and secure operation Cooking zones 1 induction cooking zone ø 11" (2600 W, with booster 3600 W). 1 induction cooking zone ø 7" (1800 W, with booster 3100 W). 1 induction cooking zone ø 6" (1400 W, with booster 2200 W). Operation Control knobs with illuminated ring. Integrated control panel. Electronic power control in 17 output levels. Features Cooking zone marking. Frying sensor function. Pot detection. Booster function for each cooking zone. Safety Residual heat indicator. Operation indicator. Safety shut-off. Planning notes Operates with magnetic (induction) iron pots and pans only. For an optimal heat distribution, the use of flat bottom cookware is recommended. Appliance can be snapped into the countertop from above. Appliance weight: approx. 16 kg. Rating Total rating: Connected load: 7400 W Plan for a 37"connecting cable without plug (hardwire required).
Specification
| General | |
| Product group | Hob |
| Brand | Gaggenau |
| Product name / series name | Cooking zone ceramic |
| SKU | VI263620 |
| Internal article number | VI263620 |
| EAN code | 4242006280512 |
| Construction type | Built-in |
| Type of control | Mechanical |
| Type of control | Cylindrical controls;Illuminated |
| Energy input | Electric |
| Total number of cooktop burners | 3 |
| Number of gas burners | 0 |
| Number of electric cooking zones | 3 |
| Number of electric elements | 0 |
| Number of radiant elements | 0 |
| Number of halogen elements | 0 |
| Number of induction elements | 3 |
| Number of electric warming zones | 0 |
| Location of control panel | Front |
| Power Cord Length | 37" |
| Basic surface material | Ceramic |
| Overall appliance dimensions (HxWxD) | 5/16"+4 15/16" x 22 13/16" x 20 3/16" |
| Type of frame | Frame |
| Color of frame | Stainless Steel |
| Current (A) | 30 |
| Dimension of 2nd heating element | 11" |
| Volts (V) | 208-240 |
| Frequency (Hz) | 60 |
| Power cord length (cm) | 96.0 |
| Plug type | No Plug |
| Dimension of 5th heating element | 7" |
| Height of the packed product (mm) | 200 |
| Width of the packed product (mm) | 610 |
| Depth of the packed product (mm) | 700 |
| Product packaging dimensions (HxWxD) | 7.87 x 24.01 x 27.55 |
| dishwasher safe pan support | No |
| Minimum height for installation (mm) | 492 |
| Maximum height for installation (mm) | 492 |
| Minimum width for installation (mm) | 560 |
| Maximum width for installation (mm) | 560 |
| Depth for installation (mm) | 125 |
| Net weight (kg) | 16.1 |
| Gross weight (kg) | 16.9 |
| Highlights | 5 frying levels, fryingSensor Plus, Keep warm function, powerBoost |
| Automatic programmes | Yes |
| Location of the heating element | front left |
| Location of 2nd heating element | center left |
| Type of 2nd heating element | Induction heating |
| Dimension of 2nd heating element (mm) | 280 |
| Burners with booster | All |
| Power of 2nd heating element (kW) | 2.6 |
| Location of 3rd heating element | back left |
| Location of 4th heating element | middle back |
| Knob Material | Full metal |
| Location of 5th heating element | back right |
| Type of 5th heating element | Induction heating |
| Dimension of 5th heating element (mm) | 180 |
| Power of 5th heating element (kW) | 1.8 |
| Location of 6th heating element | center right |
| Power of 2nd heating element (kW in boost) | 3.7 |
| Power of 5th heating element (kW in boost) | [3.1] |
| Minimum distance from counter front | 2" |
| Minimum distance from rear wall | 2" |
| Power on indicator | No |
| Required cutout size (HxWxD) | 4 15/16" x 22 1/16" x 19 3/8" |
| Plate on indicator | 0 |
| Type of regulation | Stepless energy regulated |
| Type of lid | Without |
| Ignition system | No |
| Main on/off switch | No |
| Safety device | Auto Safety Shutoff;pan recognition |
| Timer | No |
| Included accessories | 1 x glass scraper |
| Additional Image 1 | https://media3.bsh-group.com/Product_Shots/3000x3000/MCIM02749217_VarioCooktops200_Deailshot_def.jpg |
| Additional Image 2 | https://media3.bsh-group.com/Product_Shots/3000x3000/MCIM02751622_VarioCooktops200_Deailshot_Variation_Slate_def.jpg |
| Additional Image 3 | https://media3.bsh-group.com/Product_Shots/3000x3000/17624112_GG_GL_Cooking_200_2SHS07Ce_us_3_def.jpg |
| Sealed Burners | No |
| UPC code | 825225950110 |
| Gross weight | 37.000 |
| Net weight | 36.000 |
